SL1.100.150.40.4.51D.C Sewage Pump For Industrial Waste Water Rated Flow Rate 195 L/S Maximum Working Pressure 10bar

Brand Name : Grundfos

Model Number : SL1.100.150.40.4.51D.C

MOQ : 1

Price : Negotiable price

Payment Terms : L/C,D/A,D/P,T/T,Western Union,MoneyGram

Supply Ability : 100

Delivery Time : 10--60 workdays

Packaging Details : Wooden box

Rated flow rate : 195 L/S

Rated head : 8.28 m

Actual impeller diameter : 379.4 mm

Ambient temperature range : 0 - 40 °C

Maximum operating pressure : 5 bar

Liquid temperature range : 0 - 40 °C

Liquid temperature during operation : 20 °C

Density : 998.2 kg/m³

Rated power - P2 : 18.5 kW

Power supply frequency : 50 Hz

Rated voltage : 3 x 380 - 415 V

Maximum head : 16 m

Maximum flow rate : 349 L/S

Maximum working pressure : 10bar

Contact Now

SL1.100.150.40.4.51D.C
The non-self-priming single-stage centrifugal pump is designed for handling wastewater, production water and unfiltered raw sewage. This pump is designed for intermittent and continuous operation with submersible installation. The revolutionary S-tube® impeller provides a spherical passage that can handle solids with a size of 100 millimeters and is suitable for wastewater with a dry matter content of up to 3%. The unique stainless steel clamp assembly system enables the pump to be quickly and conveniently detached from the motor unit, facilitating maintenance and inspection. No specialized tools are required.



Submersible Sewage Pump
SL1
Suitable for:

  • Commercial Sewage Treatment
  • Industrial Wastewater
  • Sewage Transportation
  • Flood Control and Drainage
  • Sewage Treatment

    Sewage Pump


 SL1.100.150.40.4.51D.C Sewage Pump For Industrial Waste Water Rated Flow Rate 195 L/S Maximum Working Pressure 10bar


Controller:
Humidity Sensor: There is a humidity sensor.
Capacitive Sensor for Detecting Impurities in the Liquid: There is no oil and water content sensor.


Liquid:
Liquid Temperature Range: 0 - 40 °C
Liquid Temperature during Operation: 20 °C
Density: 998.2 kg/m³


Technology:
Rated Flow Rate: 38.3 liters per second
Maximum flow: 64.4 liters per second
Rated Head: 6.5 meters
Type of impeller: S-TUBE
Max. Particle: 100 millimeters
Main Shaft Seal: SIC/SIC
Approvals: CE EN12050-1
Curve tolerance: ISO9906:2012 3B2
Cooling jacket (Yes/No): No


Materials:
Pump Casing: Cast iron
Pump housing: EN 5.1301 EN-GJL-250
Impeller: Cast iron
EN 5.1301 EN-GJL-250
Motor: EN-GJL-250


Installation:
Ambient Temperature Range: 0 - 40 °C
Maximum Operating Pressure: 6 bar
Type of inlet connection: DIN
Type of outlet connection: DIN
Size of inlet connection: DN 150
Outlet Size: DN 150
Pressure rating for pipe connection: PN 10
Maximum installation depth: 7 meters
Auto coupling: 96090995
Structural Range: C


Electrical Data:
Power input P1: 4.8 kW
Rated power - P2: 4 kW
Power Supply Frequency: 50 Hz
Rated voltage: 3 x 380-415 V
Voltage Difference: +10/-10 %
Maximum Number of Starts per Hour: 20
Rated current: 9.6 A
Starting Current: 65 A
Cos phi - Power Factor: 0.72
Cos phi - Power Factor at 3/4 Load: 0.63
Cos phi - Power Factor at 1/2 Load: 0.50
Rated driver speed: 1464 revolutions per minute
Motor Efficiency at Full Load: 87.4 %
Motor Efficiency at 3/4 Load: 87.1 %
Motor Efficiency at 1/2 Load: 85.0 %
Number of Motor Poles: 4
Starting Method: SD
Enclosure Rating (IEC 34-5): IP68
Insulation class (IEC 85): H
Explosion-proof: No
Self-protection Standard: THERMAL SWITCH
Cable type: LYNIFLEX
Length of power cable: 10 meters
Power plug: No plug


Others:
Net Weight: 166 kg
Gross weight: 187 kg
